Karcepts S2000 Rear Sway Bar Kit, .0875” O.D. x Solid Bar

Sorry - this product is no longer available

SKU: KRSB_solid
This is the solid bar version. Really fine tune your S2000 balance with a rear sway bar. Depending on a number of things (tires, power level, type of driving/competition), we'll use the rear bar to change the car's balance. Generally, if you have a hard time getting the power to stick, loosen the rear bar until you can get the power down without drama.
+ -

The Karcepts S2000 Rear Sway Bar Kit was designed primarily for square tire setups, but may be used by anyone looking to tame down the on-throttle oversteer characteristics of their S2000. The large OE S2000 rear sway bar is fun for drifting around, but is not always the quickest way around course. Both Karcepts rear bar options offer the ability to run much softer rate than the OE configuration, which compliments setups where higher spring rates are utilized. A softer rear bar will keep similar corner entry and mid corner character in the chassis, but will be most impactful on corner exit when trying to put power down. With 13 available stiffness settings, and two center section options, the perfect compromise between rotation and forward drive can be found for every chassis setup, surface condition, and driving style.

  • Sway bar rate is adjusted with one wrench, in only a few minutes
  • Rate adjustments are made with the vehicle on the ground, even at low ride heights
  • 13 possible adjustment settings, maximizing tunability and overall range
  • Billet aluminum arms optimized for strength and weight utilizing the latest FEA software
  • Light weight, zero deflection solid sway bar mounts provided for precise feel
  • Low friction, self-lubricating, solid polymer bearings eliminate bushing bind
  • Heat treated and plated steel alloy PTFE lined endlinks and all hardware included
  • 0.875" diameter high-grade spring steel splined center section for consistent rates
  • Center section available in 0.095” wall thickness or a solid bar

OE S2000 Rear Sway Bars:
2000-2001 = 427 lbs/in
2002-2003 = 396 lbs/in
2004-2009 = 311 lbs/in
2008-2009 CR = 362 lbs/in

Karcepts S2000 Rear Sway Bar Kit - .0875” O.D. Solid Bar:
Hole 1/1 = 206 lbs/in
Hole 1/2 = 219 lbs/in
Hole 2/2 = 232 lbs/in
Hole 2/3 = 248 lbs/in
Hole 3/3 = 263 lbs/in
Hole 3/4 = 282 lbs/in
Hole 4/4 = 301 lbs/in
Hole 4/5 = 323 lbs/in
Hole 5/5 = 345 lbs/in
Hole 5/6 = 371 lbs/in
Hole 6/6 = 397 lbs/in
Hole 6/7 = 425 lbs/in
Hole 7/7 = 452 lbs/in
Kit Weight = 10.5 lbs
